Slim 20" fit with interior basket drawers for optimum cold storage

Slim 20" width

• 2.8 capacity inside a slim footprint

ADA compliant

• 32" high meets ADA guidelines

Fully finished white cabinet

• Allows the unit to be used freestanding

Factory installed lock

• Top-mounted for convenient security

Reversible door

• Keep your options flexible with a reversible door that is easy to switch when your arrangement changes

Manual defrost

• Efficient performance with reliable temperature stability

-20º capable

• Low temperature capability ideal for certain sensitive items

Pull-out drawers

• Four clear baskets for convenient and separated storage

Adjustable thermostat

• Rear mounted to prevent accidental adjustments

Flat door liner

• Easy to clean, with more depth for storage

100% CFC Free

• Environmentally friendly design with no ozone-damaging chemicals

Matching refrigerator available

• Pair with FF511LADA all-refrigerator for a complete ADA compliant set

Exterior
DL2 Temperature Logger USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout	TT Thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	DT Digital Thermostat Install a digital thermostat with external readout for precise temperature management
Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations	KEY Extra keys available for purchase
SCD Self-Closing Door Protect interior contents and reduce energy waste with the Self Closing Door Option	LHD Door reversal to left hand swing
Latch Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.	HUM Humidity Sensor Humidity sensor with min/max readout
DL1 Temperature Logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac	Agion Door Treat the door with Agion silver antimicrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface

Freezer
Door Swing	RHD
Reversible	Yes
Interior Height	26.38" (67 cm)
Interior Width	14.0" (36 cm)
Interior Depth	16.75" (43 cm)
Thermostat Type	Dial
Refrigerant Type	R134a
Refrigerant Amount	3.0 oz.
High Side PSI	210.0
Low Side PSI	105.0
Level Legs	2
Interior Drawers	Yes
Drawers Qty	4

Lock
KEYPAD Battery-powered keypad lock installed for keyless security	AC Keypad Keypad lock powered by appliance power cord for keyless security

Overview
Height of Cabinet	32.0" (81 cm)
Height to Hinge Cap	32.5" (83 cm)
Width	19.25" (49 cm)
Depth	21.38" (54 cm)
Depth with Handle	23.0" (58 cm)
Depth with door at 90°	39.5" (100 cm)
Capacity	2.8 cu.ft. (79 L)
Defrost Type	Manual
Door	White
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Amps	1.6
Voltage/Frequency	115 V AC/60 Hz
Weight	64.0 lbs. (29 kg)
Shipping Weight	80.0 lbs. (36 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
