Model #:
JBS360DMBB
Color:
Black
GE® 30" Free-Standing Electric Range
GE® 30" Free-Standing Electric Range
Price
We might not be able to fulfill your order for the quantity requested
Dimensions
Width: 30
Height: 47
Depth: 28 3/4
Color
Black
Also Comes In
Model #:
JBS360DMWW
White
Features
5.0 cu. ft. oven capacity
- Cook more dishes at once
- Smooth surface and rounded corners make clean-up quick and easy
- Enjoy the same cooking power as a traditional coil with an added safety feature that meets the new UL858 Household Electric Ranges Standard for Safety
- Help cooks coordinate meal preparation and cooking
- Large trays and other cookware can be conveniently stored for quick access
- Upper and lower elements produce even heat and great results
Product Description
GE® 30" Free-Standing Electric Range
Specification
| APPEARANCE | |
| Handle | Designer Style |
| Textured Steel Side Panels | Yes |
| Oven Door Features | Big View Oven Window, Glass Door |
| Handle Color | Black |
| Control Knobs | Black |
| Color Appearance | Black |
| CAPACITY | |
| Total Capacity (cubic feet) | 5 cu ft |
| FEATURES | |
| Cooking System | Traditional |
| Storage Drawer Features | Removable Full-Width |
| Oven Interior | 1 Incandescent Light |
| Oven Control Features | Audible Preheat Signal, Auto Oven Shut-Off with Override, Control Lock Capability, Electronic Clock & Kitchen Timer, Hi / Low Broil, Oven "ON" Light |
| Lift-Up Cooktop With Support Rods | Yes |
| Oven Rack Features | 2 Oven Racks |
| Element - Left Front | 6" 1250W Temp Limiting Coil |
| Oven Cleaning Type | Standard Clean |
| Product Type | Free-Standing Single Oven |
| Heating Element "ON" Indicator Light | Yes |
| Cooktop Type | Coil |
| Fuel Type | Electric |
| Element - Right Front | 8" 2400W Temp Limiting Coil |
| Control Location | Backsplash |
| Control Type | Digital Temperature Display, Electronic, Touchpads |
| Drawer Type | Storage |
| Sabbath Mode | Yes |
| Element - Left Rear | 8" 2400W Temp Limiting Coil |
| Cooking Technology | Traditional |
| Configuration | Range with Storage Drawer |
| Oven Features | 4-Pass Bake Element, 4-Pass Broil Element |
| Removable One-Piece Drip Bowls | Black Porcelain Enameled |
| OU Certified | No |
| Cooktop Burner Type | Coil |
| Element - Right Rear | 6" 1250W Temp Limiting Coil |
| Cooktop Surface | One-Piece Upswept, Porcelain-Enamel |
| Oven Rack Positions (Single or Upper/Lower) | 6 |
| FILTER | |
| App Filter - Cabinet Width | Cooking 30 in. (Standard) |
| App Filter - Control Type | Electronic touchpad |
| App Filter - Product Type | Ranges Free-Standing Single Oven |
| App Filter - Fuel Type | Electric |
| App Filter - Cooking Technology | Traditional |
| App Filter - Convection | No |
| App Filter - Drawer Type | Storage |
| App Filter - Cleaning Type | Manual |
| App Filter - Voltage | 240V |
| App Filter - Cooktop Type | Coil |
| POWER / RATINGS | |
| Electrical Requirements | 208/240V ; 60Hz ; 40A |
| Amp Rating at 208V | 40 |
| Broiler Wattage | 3410W |
| Amp Rating at 240V | 40 |
| KW Rating at 240V | 10.2 |
| Bake Wattage | 2585W |
| KW Rating at 208V | 7.6 |
| WARRANTY | |
| Parts Warranty | Limited 1-year entire appliance |
| Labor Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
| WEIGHTS & DIMENSIONS | |
| Net Weight | 142 lb |
| Depth Without Handle | 26.25 in |
| Height to Cooking Surface (in.) | 36 - 36 1/2 |
| Cabinet Width | 30 in |
| Approximate Shipping Weight | 162 lb |
| Overall Width | 30 in |
| Overall Height | 47 in |
| Overall Depth | 28.75 in |
| Depth with Door Open | 46.25 in |
| Oven Interior Dimensions (W x H x D) (in.) | 23-3/4 x 19 x 18-1/2 |
Documentation
From the Manufacturer
GE® 30" Free-Standing Electric Range
Features
5.0 cu. ft. oven capacity
- Cook more dishes at once
- Smooth surface and rounded corners make clean-up quick and easy
- Enjoy the same cooking power as a traditional coil with an added safety feature that meets the new UL858 Household Electric Ranges Standard for Safety
- Help cooks coordinate meal preparation and cooking
- Large trays and other cookware can be conveniently stored for quick access
- Upper and lower elements produce even heat and great results
