Counter Depth Refrigerator 17.5 cu ft

• Your fridge adapts to daily use by cooling and defrosting only when needed. This means your fridge uses the energy it needs without compromising on food care.

• Our fridges are designed and built using quality materials. We use pre-painted steel on our fridges and solid glass for shelving.

• Spill-safe secure glass shelves easily capture any drips or leaks and prevent them from falling on items below.

• This fridge is designed to make it simple for you to store, access and remove food. Storage bins give you full access inside when they’re pulled open and can be easily removed to clean. Our flexible shelving also gives you more storage options.

• ActiveSmart™ refrigerators intelligently adapt to daily use to save energy, cooling, defrosting and using energy only when they need to, without compromising on food care.

Capacity
Freezer volume	5.2 cu ft
Refrigerator volume	12.3 cu ft
Total volume	17.5 cu ft

Consumption
Energy Star Certified	yes
Energy usage	454kWh/year

Design
Bottom freezer	true
Concealed hinges	true
Door opening	left hinge
Flat door design	true
Sleek side mounted plastic handles	true

Details
UPC Code	822843245314

Freezer
Bottle chill	true
Clear plastic bins	2
Door alarm	true
Fast freeze	true
Ice tray	2
Large plastic bin	true
Slide Out Pastry Tray	true

Measurements
Depth - door closed not including handle	27-3/8"
Height - to top of cabinet	67-3/4"
Minimum air clearance - at rear	1-3/16"
Minimum air clearance - each side	13/16"
Minimum air clearance - on top	2"

Performance
ActiveSmart™ Foodcare	true
Adaptive defrost	true
Bottle chill mode	true
Fast freeze	true
Frost free	true
Humidity controlled crisper bin	true
Inverter controlled compressor	true
Sabbath mode	true

Product Identifier
Capacity - Refrigeration	15 cu ft-19.9 cu ft
Dimension	30'-35"
Energy rating	Energy star
Material / Color	White

Product Type
Refrigeration Type	Bottom Freezer

Refrigerator
Adjustable door shelves	4
Adjustable glass shelves	4
Covered door shelves	2
Door alarm	true
Front levelling feet	true
Fruit and vegetable bins	2
Full extension runners	true
Full width door shelves	2
LED lighting	true
Rear rollers	true
SmartTouch control panel	true
Spill proof removable bins	true
Stackable bottle holders	2

Style And Series
Product Series	Series 5
Product Style	Contemporary

Warranty
Parts & Labor	2 years
Sealed system parts	5 years

• ActiveSmart™ Refrigerator User Guide

• ActiveSmart™ Refrigerator Guide D’Utilisation

• Réfrigérateur ActiveSmart™ Modèles Ice & Water, Automatic Ice et autres que Ice & Water - Instructions d'installation et guide d'utilisation

• ActiveSmart™ Refrigerator Ice & Water, Automatic Ice and non-Ice & Water - RF135B, RF170B, RF170W, RF170A and RF201A models: Installation instructions and user guide

• Energy Label - Fridge - RF170B Model
